- Adjustable laser marker for precise cutting lines easily adjustable to users preference
- 12 Amp motor for the toughest cutting jobs
- 57 Degree miter angle to the right, for ultra flexibility with 45 degree miter angle to the left
- 0-45 Degree bevel angle range, to the right and left allowing users to quickly and easily flip the saw blade and leave the material in place
- Positive stops on miter and bevel scale, for easy to read measurements and quick settings
- Linear ball bearing slide system with white on black miter scale for superior accuracy and visibility
- Electronic speed control maintains RPM while cutting, and improves control
- Soft start function reduced noise and recoil during start-up
- Adjustable pivot fence broadly supports work piece for improved stability while cutting
- Electric brake feature halts the rotation of the blade within seconds preventing unintended cuts
- Carbon brush access allows user to replace brush as needed to greatly prolong the life of the tool
- Highly efficient dust collector attachment collects more dust than previous models
- Splinter guard prevents material from splintering and increases safety
- Download the C10FSHPS Tool Card
Includes:
- 10" 40T TCT Saw Blade (310878)
- Pivoting Flip Fence (321385)
- 10mm Box Wrench (940543)
- Dust Bag (998845)
Optional Accessories:
- Crown Molding Vice Assembly (321434)
- Left Stopper (321374)
- Right Stopper (321373)
- Right Sub-Fence Assembly (321387)
Interested in this item or want more information?
Hours:
Phone: 401-739-9200
Email: customerservice@warwickfasteners.com
Can't find what you want? Give us a call and we can help you find it.
Details
| Amps |
12 |
|
|
|
|
| Laser Marker |
Yes |
|
|
|
|
| No-Load Speed |
3,800 RPM |
|
|
|
|
| Blade Diameter |
10" |
|
|
|
|
| Arbor Size |
5/8" |
|
|
|
|
| Bevel Angle Range: R & L |
0-45°
|
|
|
|
|
| Bevel Cross Cut at 90° (L) |
2-3/16" x 12" |
|
|
|
|
| Bevel Cross Cut at 90° (R) |
1-3/16" x 12" |
|
|
|
|
| Bevel Stops: Right and Left |
0° and 45° |
|
|
|
|
| Miter Angle Range: Right |
0-57° |
|
|
|
|
| Miter Cross Cut at 57° (R) |
3-11/32" x 6-1/2" |
|
|
|
|
| Miter Angle Range: Left |
0-45° |
|
|
|
|
| Miter Cross Cut at 45° (L/R) |
3-11/32" x 8-19/32" |
|
|
|
|
| Miter Detent Stops: Right and Left |
0°, 15°, 22.5°, 31.6° and 45° |
|
|
|
|
| Miter 45° (L/R) + Bevel 45° (L) |
2-3/16" x 8-19/32" |
|
|
|
|
| Miter 31° (L) + Bevel 45° (R) |
1-3/16" x 10-7/32" |
|
|
|
|
| Miter 45° (L/R) + Bevel 45° (L) |
1-3/16" x 8-19/32" |
|
|
|
|
| Weight |
43 lbs |
|
|
|
|
Additional Information
Manufacturer: Metabo - Hitachi
